Features

• All in one functionalities with audio codec, digital amplifier and speaker
• High-intelligibility performance with G.722&Opus codecs
• Support up to 10 multicast zones with prioritization
• Audio power up to 20W with built-in class D amplifier
• Support talkback with built-in microphone
• Customize the WAV file for emergency notification and alarming
• Linkage with security alarming devices
• Support remote configuration via web page and auto-provisioning
• 10/100 Mbps Ethernet, Integrated PoE(IEEE 802.3af, class 0)
• Ideal for school, office, station, retail, factory, etc.

Specifications

Physical
• DC port x1: DC power input
• Port:2 Pin terminal socket
• RJ45 port x1: connect the network
• Power over Ethernet(IEEE 802.3af, class 0)
• Short circuit input and output port x1(built in relay)
• Relay:MAX DC30V/2A
• Port:terminal socket
• Blue LED x1:Power status
• DC power input: DC 12~24V/2A
• Working temperature: -20℃~ 50℃
• Storage temperature: -30℃~ 60℃
• Working humidity: 10~95%
• Installation: Ceiling-mounted
• Color: White
• Device overall dimensions: 238.5mm x 238.5mmx 148.3mm
• Device back box dimensions: 202.5mmx 202.5mmx 139mm
• Gift box dimensions: 270mm x 270mmx 188mm
• Outer CTN dimensions: 560mm x 283mmx 410mm(10PCS)
