Features

•2.4-inch 320x240 pixel color screen
•Support audio codec G.722 and Opus, HD audio on speakerphone and handset
•Support 6-party local conference
•Support EHS wireless headset
•Dual 10/100/1000 Mbps ports, integrated PoE
•Two installation methods of desktop stand and wall mountable
•4 SIP Lines
•HD Voice
•PoE Enabled
•2.4-inch color screen
•Handset / Hands-free / Headset mode
•Desktop Stand / Wall mountable (optional)
•Optional External Power Supply

Specifications

Phone Functions
•  Local Phonebook (1000 entries)
•  Remote Phonebook (XML/LDAP, 1000 entries)
•  Call logs (In/Out/Missed, 600 entries)
•  Blocked List/Allowed List
•  Screen saver
•  Voice Message Waiting Indication (VMWI)
•  Programmable DSS/Soft keys
•  Network Time Synchronization
•  Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
•  Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
•  Support Recording (Through Server)
•  Action URL / Active URI
•  uaCSTA

Call Functions
•  Call out / Answer / Reject
•  Mute / Unmute (Microphone)
•  Call Hold / Resume
•  Call Waiting
•  Intercom
•  Caller ID Display
•  Speed Dial
•  Anonymous Call (Hide Caller ID)
•  Call Forward (Always/Busy/No Answer)
•  Call Transfer(Attended/Unattended)
•  Call Parking/Pick-up (Depending on server)
•  Redial
•  Do-Not-Disturb
•  Auto-Answering
•  Voice Message (On server)
•  6-way Conference
•  Hot Line
•  Hot desking

Audio
•  HD Voice Microphone/Speaker (Handset/Hands-free, 0~7KHzFrequency Response)
•  Wideband ADC/DAC 16KHz Sampling
•  Narrowband Codec: G.711a/u,G.723.1,G.726, G.729A/B, iLBC
•  Wideband Codec: G.722,Opus
•  Full-duplex Acoustic Echo Canceller (AEC)
•  Voice Activity Detection (VAD) / Comfort Noise Generation(CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR) /Automatic Gain Control (AGC)
•  Packet Loss Concealment(PLC)
•  Dynamic Adaptive JitterBuffer
•  DTMF: In-band, Out-of-Band (RFC2833/ SIPINFO)
•  VQM voice quality monitoring

Network
•  Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
•  IP Mode:IPv4/IPv6
•  IP Configuration: Static IP / DHCP / PPPoE
•  Network Access Control: 802.1x
•  VPN: L2TP / OpenVPN
•  VLAN
•  LLDP
•  QoS
•  RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Protocols
•  SIP2.0 over UDP/TCP/TLS
•  RTP/RTCP/SRTP
•  STUN
•  DHCP
•  IPv6
•  LLDP
•  Layer 2 QoS(802.1Q,802.1P)
•  PPPoE
•  802.1x  L2TP
•  OpenVPN
•  SNTP
•  FTP/TFTP
•  HTTP/HTTPS
•  TR-069
•  AES128 & AES256

Deployment & Management
•  Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCPOPT66/SIPPNP/TR-069
•  Web ManagementPortal
•  Web-based Packet Dump
•  Configuration Export / Import
•  Phonebook Import/Export
•  Firmware Upgrade
•  Syslog

Physical
•  LCD: 2.4-inch (320x240) Color Screen
•  Keypad: 36 keys, including
•  4 Soft-keys
•  9 Function keys(Hold/Transfer/Voice message/Conference/Phonebook/MWI/Headset/Redial/Hands-free)
•  3 Line keys(With LED Indicator Light)
•  4 Navigation keys
•  1 OK key
•  12 Standard Phone Digits keys
•  3 Volume Control keys(Up/Down/Mute (Microphone))
•  Handset (RJ9) x1
•  Standard RJ9 Handset Wire x1
•  1.5M CAT.5E Ethernet Cable x1
•  Desktop Stand x1
•  Status Indicator Light x1 (Red)
•  RJ9 Port x2: Handset x1, Headset x1
•  RJ45 Port x2: Network x1, PC x1 (Bridged toNetwork)
•  Security Slot x1
•  DC Power Input: DC5V / 0.6A
•  Power over Ethernet(IEEE 802.3af)class 1
•  Power Consumption(Adapter): 0.84~1.43W
•  Power Consumption(PoE): 1.32~2.09W
•  Working Temperature: 0~45℃
•  Working Humidity: 10~95%
•  Installation:
•  Desktop Stand
•  Wallmountable ( optional)
•  Color: Black
•  N.W/CTN: 8.55kg
•  G.W/CTN: 9.26kg
•  Device Dimensions:
•  Desktop Stand (45°): 169x201.1x177.4mm
•  Desktop Stand (50°): 169x191.9x185.8mm
•  Wall mountable: 169x120.1x213.7 mm
•  Gift Box Dimensions: 250x220x55mm
•  Outer CTN Dimensions: 460x300x270mm(10 PCS)
