Features

• 6 SIP lines
• 2.7” graphical Dot-matrix screen with backlight
• Support audio codec G.722 and Opus, HD audio on speakerphone and handset
• Support 6-party local conference
• Available to link with security products, can be easily customized into various security solutions for reducing investment
• Dual Gigabit ports, integrated PoE
• Up to 15 DSS keys, every DSS key can be set as Line/BLF/ Speed Dial Key

Phone Features
• Local Phonebook (1000 entries)
• Remote Phonebook (XML/LDAP, 1000 entries)
• Call logs (In/out/missed, 1000 entries)
• Blocked List/Allowed List
• Screen saver
• Voice Message Waiting Indication (VMWI)
• Programmable DSS/Soft keys
• Network Time Synchronization
• Support Bluetooth headset (Via BT dongle BT20)
• Support Wi-Fi Dongle (Via WF20)
• Support Poly wireless headset (Through Poly APD-80 EHS Cable)
• Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
• Support Recording(through server)
• Action URL / Active URI
• uaCSTA
• Dial Plan
• SIP Hotspot

Audio
• HD Voice Microphone/Speaker (Handset/Hands free, 0 ~ 7KHz Frequency Response)
• HAC handset
• Wideband ADC/DAC 16KHz Sampling
• Narrowband Codec: G.711a/u, G.723.1, G.726, G.729A/B, iLBC
• Wideband Codec: G.722, Opus
• Full duplex Acoustic Echo Canceller (AEC)
• Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer
• DTMF: In band, Out of Band (RFC2833/ SIP INFO)
• VQM voice quality monitoring

Network
• Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
• IP Mode:IPv4/IPv6/IPv4&IPv6
• IP Configuration: Static IP / DHCP / PPPoE
• Network Access Control: 802.1x
• VPN: L2TP / OpenVPN
• VLAN
• LLDP
• CDP
• QoS
• RTCP XR (RFC3611), VQ RTCPXR (RFC6035)
• WIFI:WI FI Security Mode WPA /WPA2 PSK/802.X EAP

Protocols
• SIP2.0 over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN
• DHCP
• CDP
• LLDP
• PPPoE
• 802.1x
• OpenVPN
• SNTP
• FTP/TFTP
• HTTP/HTTPS
• TR 069
• AES128 & AES256

Deployment & Management
• Auto Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP
• Multicast
• Action Plan
• Group listening

Call Features
• Call out / Answer / Reject
• Mute / Unmute (Microphone)
• Call Hold / Resume
• Call Waiting
• Intercom
• Caller ID Display
• Speed Dial
• Anonymous Call (Hide Caller ID)
• Call Forwarding (Always/Busy/No Answer)
• Call Transfer (Attended/Unattended)
• BLF
• Call Parking/Pick-up (Depending on server)
• Redial
• Do-Not-Disturb
• Auto-Answering
• Voice Message (With server)
• 6-way Conference
• Hot Line
• Hotdesking

PNP/TR 069
• Web Management Portal
• Web based Packet Dump
• Configuration Export / Import
• Phonebook Import/Export
• Firmware Upgrade
• Syslog

Physical Specifications
• LCD:2.7 inch (192x64) graphical LCD with backlight
• Keypad: 37 keys, including
➢ 6 DSS keys with LED indicator light
➢ 6 Function keys (Contact, Hold, MWI, Mute, Headset, Redial)
➢ 4 Soft keys
➢ 4 Navigation keys
➢ 1 OK key
➢ 1 Return key
➢ 12 Standard Phone Digits keys
➢ 2 Volume Control keys, Up/Down
➢ 1 Hands free key
• HD Handset (RJ9) x1
• Standard RJ9 Handset Wire x1
• 1.5M CAT5.E Ethernet Cable x1
• Desk Stand x1
• Status Indicator Light x1 (Red)
• RJ9 Port x2: Handset x1, Headset x1
• RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
• USB2.0 Port x1: Standard A, Connect with Flash Driver&USB headset and USB dongle
• Security lock port x1
• Power: DC5V/1A or PoE
• Power dissipation: standby 0.84W , high: 4.29W (Power supply)
• Power dissipation: standby 1.53W, high: 6.56W (POE)
• Working Temperature: 0~45℃
• Working Humidity: 10~95%
• Installation:
➢ Desktop Stand
➢ Wall mounted (need an additional wall hanging parts)
• Color: Gunmetal
• Qty/CTN: 10pcs
• N.W/CTN: 11.8 kg
• G.W/CTN 12.79 kg
• Device Dimensions:204x202x31mm
• Gift Box Dimensions: 307x258x71 mm
• Outer CTN Dimensions: 5536x380x327 mm (10 PCS)

Specifications

Physical

•LCD:2.7-inch (192x64) graphical LCD with backlight
•Keypad: 37 keys, including
•6 DSS keys with LED indicator light
•6 Function keys (Contact, Hold, MWI, Mute, Headset, Redial)
•4 Soft-keys
•4 Navigation keys
•1 OK key
•1 Return key
•12 Standard Phone Digits keys
•2 Volume Control keys, Up/Down
•1 Hands-free key
•HD Handset (RJ9) x1
•Standard RJ9 Handset Wire x1
•1.5M CAT5.E Ethernet Cable x1
•Desk Stand x1
•Status Indicator Light x1 (Red)
•RJ9 Port x2: Handset x1, Headset x1
•RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
•USB2.0 Port x1: Standard A, Connect with Flash Driver&USBheadset and USB dongle
•Security lock port x1
•Power: DC5V/1A or PoE
•Working Temperature: 0~45?
•Working Humidity: 10~95%
•Installation:
-Desktop Stand
-Wall-mounted (need an additional wall hanging parts)
•Color: Gunmetal
•Device Dimensions:204x202x31mm
•Gift Box Dimensions: 307x258x71 mm
