Features

<p>- Stand-alone FXS VoIP gateway with carrier-grade features and reliability.<br /> - Fully compliant with SIP and IAX2, also features flexible calling rules.<br /> &bull;Answer Detection<br /> &bull;Attack Alert<br /> &bull;Auto Provisioning with Yeastar IP-PBX<br /> &bull;Backup and Restore<br /> &bull;Call Back<br /> &bull;Call Detail Records<br /> &bull;Caller ID Display<br /> &bull;Firewall<br /> &bull;Firmware Upgrade by HTTP/TFTP</p> <p>&bull;Hangup Detection<br /> &bull;IP Blocklist<br /> &bull;Nat Traversal<br /> &bull;Packet Capture Tool<br /> &bull;Programmable AC Impedance<br /> &bull;System Logs<br /> &bull;Web-based Management</p>

Specifications

RJ11 FXO Ports : 8
LAN : 1 10/100Mbps
Protocol : SIP (RFC3261), IAX2
Transport : UDP, TCP, TLS, SRTP
Codec : G.711 (alaw/ulaw), G.722, G.723, G.726, G.729A, GSM, ADPCM
Fax : T.30
QoS : DiffServ, ToS, 802.1 P/Q VLAN tagging
Network : DHCP, DDNS, OpenVPN, PPPoE, Static Route, VLAN
Network Protocol : FTP, TFTP, HTTP, HTTPS, SSH
Management Protocol : RADIUS
Remote Management : N/A
Signaling : FXS Loop Start, FXS Kewl Start
FXO Connectivity : Programmable AC Impedance, Hangup Detection, Answer Detection, Caller ID Detection
Power : 12V, 1A
Dimensions (L × W × H) (mm) : 200 × 137 × 25
Mounting : Desktop, Wall-mount
Compatibility : Interoperable with Asterisk, Lync Server, FreePBX and certified with Elastix.
